Introduction

This is the only introduction you need. In this document we will explain both the theory and the math behind quantum behaviors and the experiments that prove that they are not just dreams of scientists on drugs but that they are real and verifiable.

In this document, the following two assumptions will be made:

• there are no massless paticles;
• relativistic effects are ignored.

A good “popular” introduction to relativistic effects can be found here.

Fundamentals

We will now give the fundamental tools and concepts to understand more advanced topics.

Wave-particle duality

The wave-particle duality is at the foundation of the entire field of quantum mechanics. Hoc can you prove that a particle is, in fact, a particle? Consider the following setup, where a beam of particles if thrown into a 50/50 beam-splitter:

Since the beam-splitter is a 50/50 one (this also works with any generic type of beam-splitter), both detectors A and B will measure about the same numbers of particles. If, isntead of a beam, a single particle at a time is thrown into the setup, only one of the two detector will fire for each particle, with 50/50 probability (randomness). This means that the particle is effectively a particle that moves along a trajectory and that does not propagate like a wave.

Consider now the Mach-Zender interferometer:

Intuitively, sending a beam of particles inside this setup would make both detectors measure 50% beam intensity, but this does not happen. Assuming that both the upper path and the lower path are exactly the same length, detector A will always measure 100% of the beam intensity.

Sending a particle at a time shows the same result (therefore no interference between different particles).

The mathematic modellization of the Mach-Zender interferometer will be presented here.

The Mach-Zender interferometer demonstrates that each particle also propagates like a wave, taking both the upper and the lower paths at the same time (superposition), interfering with itself at the second beam-splitter.

Superposition

We saw with the Mach-Zender interferometer that a particle is also a wave, so it cannot be described with the usual state of motion tuple (position and velocity) like we do in classical mechanics, therefore a new kind of algebra is needed.

Let |u\rangle be the quantum state (the equivalent of the state of motion) describing a particle.

Just as with the classical counterpart, knowing the quantum state of a particle at a give time, unless irreversible operations like measurements are performed, is enough information to let us compute the quantum state of the same particle forever in the past and in the future.

|u\rangle belongs to the Hilbert (i.e. a vector space with a scalar product) space \mathcal{H} that contains all the possible quantum states for the particle. Since \mathcal{H} is an Hilbert space, three operations are defined:

• (+): \mathcal{H} \times \mathcal{H} \to H \overset{\Delta}{=} |u\rangle> + |v\rangle \mapsto |u+v\rangle
• (\cdot): \mathbb{C} \times \mathcal{H} \to \mathcal{H} \overset{\Delta}{=} \alpha |v\rangle \mapsto |\alpha v\rangle
• \langle \cdot | \cdot \rangle: \mathcal{H} \times \mathcal{H} \to \mathbb{C}

The first operation is called the superposition operation, the third one is the bracket.

A generic state can be represended as a weighted sum (a.k.a. superposition or linear combination) of other states. Weights are complex numbers.

Any superposition of valid states is another valid state for the system.

|u\rangle = \sum_{j=1}^n \alpha_j |v_j\rangle \qquad |u\rangle, |v_j\rangle \in \mathcal{H}, \alpha_j \in \mathbb{C}

Measurements

A measurement is the act of extracting information about the quantum system we are working with. A measurement is always performed against an observable, i.e. a measurable quantity or property of the system.

A measurement is an irreversible operation: whenever a measurement is performed, the state collapses to one of the proper states of the observed quantity.

This means that a quantum experiment is generally not repeatable: if multiple measurements in the same conditions must be performed, the only way to do so is to create multiple replicas of the same experiments.

The probability of observing a specific observable value when performing a measurement depends on the quantum state of the system.

Let |O_j\rangle be the quantum state in which a measurement on a given observable will always yield O_j as a result and |u\rangle the quantum state of the system we are working with, then

|u\rangle = \sum_{j=1}^n \alpha_j |O_j\rangle

The various |O_j\rangles are therefore all proper states.

The \alpha_j coefficient are enough to determine the state of a quantum systemm therefore knowing \alpha = [\alpha_1, \alpha_2, \dots]^T at a specific time allows us to determine the same vector forever in the past and in the future (unless irreversible operations are performed).

The probability of observing a specific value O_j when performing a measurement is given by the Born rule.

Proper states are mutually exclusive: we cannot measure O = 3.14 and O = 2.71 at the same time. Let |O_i\rangle, |O_j\rangle be two normalized proper states, then

\langle O_i | O_j \rangle = \delta_{ji} = \begin{cases} 0 & i \ne j \\ 1 & i = j \end{cases}

Let |u\rangle be a quantum state, then \alpha_j = \langle O_j | u \rangle.

Since a measurement is a stochastic process, we can define the expectation value of an observable

\langle O \rangle = \sum O_j \cdot P(O_j)

and the measurement variance

\sigma_O^2 = \sum (O_j - \langle O \rangle)^2 P(O_j)

Vector representation

Vector representation is not to be confused with “position representation”, “energy representation” et similia. The former is used to indicate the “data structure” used in the computations, the latters are used to indicate the “basis” for those data structures. This will become clear later.

To operate numerically with quantum states, we should choose an appropriate Hilbert space that is isomorphic to the space of quantum states allowable by the quantum system we are working with. \{0\} and \mathbb{C}^n \forall n \in \mathbb{N} are all good examples of Hilbert spaces that can be used to describe quantum systems. Vectors used to describe the state of a quantum system are called statevectors.

Orthogonal states must be associated to orthogonal vectors.

The set of vectors associated to proper states must be a basis for the chosen Hilbert space, therefore multiple representations can coexist at the same time. Let

|u\rangle = \sum \alpha_j |O_j\rangle = \sum \beta_j |v_j\rangle

then

\begin{align*} \langle O_k | \sum \alpha_j | O_j \rangle &= \langle O_k | \sum \beta_i | v_i \rangle \\ \sum \alpha_j \langle O_k | O_j \rangle &= \sum \beta_i \langle O_k | O_i \rangle \\ \alpha_k &= \sum_i \langle O_k | v_i \rangle \beta_i \end{align*}

therefore, if \alpha = [\alpha_1, \alpha_2, \dots]^T and \beta = [\beta_1, \beta_2, \dots]^T then

\begin{align*} \alpha = \mathcal{U}\beta &\qquad\qquad \mathcal{U} = [u_{ki}] = [\langle O_k | v_i \rangle] \\ \beta = \mathcal{W} \alpha &\qquad\qquad \mathcal{W} = \mathcal{U}^T \end{align*}

Both \mathcal{U} and \mathcal{W} are unitary.

While (+) and (\cdot) are quite intuitive when using a complex vector space to describe quantum systems, the braket operator may not be so trivial:

\langle u | v \rangle = \sum_{ji} \alpha_j^* \beta_i \delta_{ji} = \sum_j \alpha_j^* \beta_j

Vector representation will be the default for discrete systems for the remaining of this document.

Discrete vs continuous systems

What we have seen so far was just for discrete systems (in the sense that observables can only assume quantized values). In reality, everything can be adapted to work for continuous systems with a few, intuitive tweaks.

Usually, it is just a matter of using integrals instead of sums and probability density functions instead of probabilities.

The quantum state describing a system can be written as

|u\rangle = \int \alpha(\xi) |O(\xi)\rangle d\xi

The statevector containing all the coefficients is now called statefunction (or, for a position observable, wave function):

\psi(x) \overset{\Delta}{=} \langle O(x) | u \rangle

The bracket is computed as

\begin{align*} \langle u | v \rangle &= \int \alpha^*(\xi) \beta(\xi) d\xi \\ \langle u | u \rangle &= \int |\alpha(\xi)| d\xi \\ \langle O(\xi) | O(\eta) \rangle &= \delta(\xi - \eta) \\ \end{align*}

\delta is the continuous extension of the Dirac delta we’ve used before:

f(\eta) = \int f(\xi) \delta(\xi - \eta)

Observables probabilities are now computed with

f(\xi) = Pdf(O(\xi)) = \frac{|\alpha(\xi)|}{\langle u | u \rangle} \\ f(\xi_0) = \lim_{\Delta \xi \to 0} \frac{P(\xi_0 \lt \xi \lt \xi + \Delta \xi)}{\Delta \xi} \\ P(\xi_1 \lt \xi \lt \xi_2) = \int_{\xi_1}^{\xi_2} f(\xi) d\xi

This representation will be the default for continuous systems for the remaining of this document.

Operators

Changes to a quantum systems are represented by changes in the corresponding statevector. Said changes are encoded in linear functions that act on the quantum state and return the modified quantum state.

Commutators

We denote with [\hat O_1, \hat O_2] the commutator of the two operators \hat O_1 and \hat O_2.

Two operators are said to commute if and only if \hat O_1 \hat O_2 = \hat O_2 \hat O_1. In this case, the order of application of the two operators does not matter.

Commutation between operators is an equivalence relation.

Let \{\hat A, \hat B, \hat C, \dots\} be a set of operators such that if two operators are in that set, they commute. We denote one of the shared eigenstates with |a_n, b_m, c_o, \dots \rangle to clearly indicate that

\begin{cases}\begin{align*} \hat A |a_n, b_m, c_o, \dots \rangle &= a_n |a_n, b_m, c_o, \dots \rangle \\ \hat B |a_n, b_m, c_o, \dots \rangle &= b_m |a_n, b_m, c_o, \dots \rangle \\ \hat C |a_n, b_m, c_o, \dots \rangle &= c_o |a_n, b_m, c_o, \dots \rangle \\ &\dots \end{align*}\end{cases}

Operators associated to observables

If an operator is linear and also hermitian (a.k.a. self adjoint, i.e. it holds that \langle u | \hat O v \rangle = \langle \hat O v | u \rangle) then it is associated with an observable.

We can write the following eigenequation

\hat O |u \rangle = O |u \rangle

The solution of said eigenequation yields all possible observables O (from now on, eigenvalues) associated with the respective proper states (from now on eigenstates).

An eigenvalue may be degenerate: in such a case, when that value is measured, the system will collapse in a superposition of the eigenstates associated to that eigenvalue.

If we knew all the possible eigenvalues and the associated eigenstates, any operator associated to an observable property can be described as

\hat O = \sum O_j |O_j \rangle\langle O_j| \\ \hat O = \int O(\xi) |O(\xi) \rangle \langle O(\xi)| d\xi

Since eigenvalues correspond to a measurable quantity, they must always be real (and they are).

A really important relation exists between operators and expectation values:

\langle O \rangle = \frac{\langle u | \hat O | u \rangle}{\langle u | u \rangle}

Heisenberg uncertainty principle

Given two operators \hat A and \hat B with the standard deviation associated to the measurement of the associated observables \sigma_A, \sigma_B, the Heisenberg uncertainty principle states that

\sigma_A\sigma_B \ge \left|\frac{i}{2} \langle u | [\hat A, \hat B]|u\rangle \right|

This meas that, in a joined measurement of A and B, it is impossible to get bot standard deviations low, no matter the precision of the instruments, this uncertainty is intrinsicly built into quantum mechanics: the lowe is one, the higher the other one.

Complex systems

A complex system is a system in which we consider multiple degrees of freedom. It may be a system composed of multiple particles or a system in which we look at different properties of the same particle (or both).

To describe a complex system, quantum states needs to belong to a tensor product of multiple Hilbert spaces, one for each particle/properties observed: a combined state may be expressed as

|u\rangle^{(1)}|v\rangle^{(2)} \in \mathcal{H}^{(1)} \otimes \mathcal{H}^{(2)}

A composite state is said to be entangled if it cannot be expressed as a product of states, all belonging to different Hilbert spaces (otherwise it is said to be disentangled).

The most general form to be used to express a generic complex system is

|w\rangle^{(1) \otimes (2)} = \sum_{ji} \gamma_{ji} |O_j\rangle^{(1)} |O_i\rangle^{(2)}

while, if the system is disentangled, it can be expressed as

|w\rangle^{(1) \otimes (2)} = \sum_{ji} \alpha_i \beta_j |O_i\rangle^{(1)} |O_j\rangle^{(2)}

It is possible to apply composite operators to composite systems: each operator is only applied to components of the state belonging to the same Hilbert space it belongs to.

If |u\rangle = |a\rangle^{(1)} |b\rangle^{(2)} then

\hat O^{(1)} \hat O^{(2)} |u\rangle = (\hat O^{(1)}|a\rangle^{(1)})(\hat O^{(2)}|b\rangle^{(2)})

It is possible to compute the probability of a joined measurement: let |w\rangle be a general complex system composed of two degrees of freedom, then the probability of measuring O_j for the first degree of freedom and, at the same time, O_i for the second one is

P = \frac{\|\gamma_{ji}\|}{\langle w|w \rangle}

Let |w\rangle = \sum_{ji} \gamma_{ji} |O_j\rangle^{(1)} |O_i\rangle^{(2)} and |y\rangle = \sum_{kl} \delta_{kl} |O_k\rangle^{(1)} |O_l\rangle^{(2)}, then

\langle w|y \rangle = \sum_{jikl} \gamma_{ji}^* \delta_{kl} \langle O_j|O_k \rangle^{(1)} \langle O_i|O_l \rangle^{(2)} = \sum_{ji} \gamma_{ji} \delta_{ji}

Continuous extension of compisite system use multidimensional integrals.

Compisite systems can be represented using vectors and the Kroneker product as tensor product.

Momentum and position operators

Position and velocity are the basic properties to describe the state of motion of a particle. In quantum mechanics we use, instead of velocity, the momentum, due to some difficulties in handling velocities in complex systems.

Both the momentum operator and the position operators operates on the position representation of a quantum state, meaning that, the quantum state must be written like

|u\rangle = \int \psi(x) |O(x)\rangle dx

where the statefunction psi is the wave function of the system (i.e. one of the functions whose square norm is the probability density function of the position distribution).

Let f(x) = |\psi(x)|^2, then

\langle x \rangle = \langle \psi(x) | \hat X | \psi(x) \rangle = \int x f(x) dx = \int \psi^*(x) x \psi(x) dx = \int \psi^*(x) \hat X \psi(x) dx

therefore, the position operator is just a “multiplication by scalar” operator:

\hat X \psi = x \psi

The n-dimensional exptension is trivial (\hat{\vec{X}} = \hat X \cdot \vec{u_x} + \hat Y \cdot \vec{u_y} + \dots).

Deriving the momentum operator is more difficult: a proof is provided below, for now just say that it can be written as

\hat P_x = -i \hbar\frac{\partial}{\partial x} \qquad \hbar = 1.054 \cdot 10^{-34} Js

In the same proof, we demonstrate that momentum eigenfunctions are shaped like

\psi(x) = Ce^{i \frac{p}{\hbar}x}

where p is the corrisponding eigenvalue.

We can add an arbitrary amount of momentum q to an eigenfunction of momentum by multiplying it by a position dependent phase factor:

\varphi(x) = e^{iqx} C e^{i\frac{p}{\hbar}x} = Ce^{i\frac{p + \hbar q}{\hbar}x}

Just as for the position operator, also the n-dimensional extension of the momentum operator is trivial:

\hat{\vec{P}} = -i \hbar \vec{\nabla}

Momentum and position operators do not commute: [\hat{\vec{P}}_x, \hat X] = -i \hbar \ne 0 therefore, according to the Heisenberg uncertainty principle we can say that

\sigma_{P_x} \sigma_x \ge \frac{\hbar}{2}

Knowing that v = \frac{P}{m} then, we can also say that

\sigma_{v_x} \sigma_x = \frac{\hbar}{2m}

Since \hbar is really small, the Heisenberg uncertainty principle is not a too strict of a limitation, even for systems as small as 1\r{A}. This is exactly the reason why classical mechanics work. It is so big that quantum uncertainty is really negligible.

Translation operator

The translation operator was already introduced in the two-hours-long proof in the previous section. We will now analyze it in more detail.

We saw that the translation operator is used to, well, translate stuff:

\hat T_R \psi(x) = \psi(x - R) = \psi(x) \left.\frac{\partial \psi}{\partial x}\right|_{R = 0} + O(R)

Since

\frac{\partial \psi}{\partial x} = \frac{i \hat P_x}{\hbar} \psi

then

\psi(x - R) = \sum_{j = 0}^\infty \frac{1}{j!}\left( -\frac{i}{\hbar} \hat P_x R \right)^j \psi(x) = \underbrace{e^{\frac{-i\hat P_x R}{\hbar}}}_{\hat T_R} \psi(x)

Energy

The energy of a particle can be a sum of multiple terms, depending on the context of the particle. Usually, it is a sum of a potential term that depends on the position and a kinetic term that depends on the momentum:

E = E(\vec{P}, \vec{r}) = V(\vec{r}) + T(\vec{P}) \\

We can already give the expansion of the kinetic term (the potential term depends on the pofition but also on the context in which the particle can be found):

T(\vec{P}) = \frac{1}{2} \frac{P^2}{m} = \frac{1}{2m} (-i\hbar \vec{\nabla})(-i\hbar \vec{\nabla}) = -\frac{\hbar^2}{2m} \vec{\nabla}^2

The operator associated with the energy observable is called hamiltonian:

\hat H = -\frac{\hbar^2}{2m} \vec{\nabla}^2 + V(\vec{r})

Having defined \hat H, we can now write the non-relativistic version of the Schrödinger equation:

\hat H \psi = E \psi

In order to solve the Schrödinger equation, we need information on the system we are working with.

Basically, we need to get the hamiltonian for each different potential and then we need to impose continuity of the solution and of it’s first derivative.

As noted in the introduction, we will ignore any relativistic effect. For a really short introduction to relativistic effects, see the video linked in the introduction.

Free particle

We will now consider a free particle, i.e. an unconstrained particle free to move anywhere in an equipotential space. Since the potential V does not depend on the position and it’s constant, we will set its origin to the constant so that V \equiv 0.

The Schrödinger equation for the free particle is also called Poisson equation and looks like this:

\hat H \psi = -\frac{\hbar^2}{2m} \vec{\nabla}^2 \psi(\vec{R}) = E \psi(\vec{r})

Solutions to this equations are shaped like

\psi(\vec{r}) = C \cdot e^{i \vec{k} \vec{r}}

therefore \|\psi\|^2 = C^2 hence, a free particle has the same probability of being anywhere.

Since

-\frac{\hbar^2}{2m}\vec{\nabla}(\vec{\nabla} C e^{i \vec{k} \vec{r}}) = ECe^{i \vec{k} \vec{r}}

we can say that the eigenvalues for the enerdy do not depend on the normalization constant C and are shaped like

E = \frac{\hbar^2 k^2}{2m}

Please note that, in this case, the eigenvalues are always positive. Considering V \ne 0, it would be possible to obtain negative eigenvalues for the kinetic term but summing them to V would always yield positive energies (see below).

\hat P and \hat H share the same set of eigenstates, so they commute:

\hat P C e^{i \vec{k} \vec{r}} = \vec{P} C e^{i \vec{k} \vec{r}} \\ -i \hbar \vec{\nabla}^2 e^{i \vec{k} \vec{r}} = \vec{P} e^{i \vec{k} \vec{r}} \\ \vec{P} = \hbar \vec{k}

therefore we could also write

E = \frac{\hbar^2 k^2}{2m} = \frac{P^2}{2m}

Let’s now consider a non-zero constant potential (e.g. we move the origin), then

\begin{align*} \hat H \psi(\vec{r}) &= -\frac{\hbar^2}{2m} \vec{\nabla}^2 \psi(\vec{r}) + V\psi(\vec{r}) = E \psi(\vec{r}) \\ &= -\frac{\hbar^2}{2m} \vec{\nabla}^2 \psi(\vec{r}) = \underbrace{(E - V)}_{E'} \psi(\vec{r}) \\ \end{align*}

meaning that

E' = \frac{\hbar^2 k^2}{2m}

We can reverse the prevoius formula to get the definition of k:

k = \sqrt{\frac{E' 2m}{\hbar^2}} = \sqrt{\frac{(E - V)2m}{\hbar^2}}

Since the origin of V can be chosen arbitrarily, it must not influence the final result in any way.

Constrained particles

When a particle is not free, it is constrained. Depending on the shape of the potential, we can say that we have a particle in a box, a potential step, a realistic potential well, a finite potential wall or an harmonic oscillator.

In the most general case, the Schrödinger equation

-\frac{\hbar^2}{2m} \frac{\partial^2}{\partial x^2} \psi(x) + V(x)\psi(x) = E \psi(x)

must remain valid everywhere and since we know that, in each section, the wave function must be a superposition of particles moving from the left and particles moving from the right, we can state that the general shape of the solution is shaped like

\psi(x) = A e^{+ ikx} + B e^{- ikx} \qquad k = \sqrt{(E - V(x)) \frac{2m}{\hbar^2}}

Once the formula for the potential is known, it is just a matter of substitution and imposition of either \psi \in \mathcal{C}^1 (in the case of non infinite barriers) of \psi \in \mathcal{C}^0 (in the other cases).

Particle in a (potential) box

A monodimensional quantum box is mathematically represented by a potential shaped like

V(x) = \begin{cases} V_0 & 0 \lt x \lt L \\ +\infty & x \le 0 \cup x \ge L \end{cases}

If that is the case, then, outside the boundaries of the box, it holds that \|\psi(x)\| = 0.

To find the energy eigenstates, we must solve the Schrödinger equations, knowing that multiple constraints must be satisfied.

First, inside the box, the particle is free and is in a superposition of “going to the left” and “going to the right”:

\psi(x) = \alpha e^{ikx} + \beta e^{-ikx}

After this, we know that \psi must be continuous so, putting everything all together, we get that

\begin{cases} |\psi(x)|^2 = 0 & x \le 0 \cup x \ge L \\ \psi(x) = \alpha e^{ikx} + \beta e^{-ikx} & 0 \lt x \lt L \\ \lim\limits_{x \to 0^+} \psi(x) = \lim\limits_{x \to L^-}\psi(x) = 0 \\ \end{cases}

The solution to this looks like

\begin{cases} \psi(x) = C \cdot \sin(kx) \qquad k = \frac{n\pi}{L} \qquad n \in \mathbb{N}^+ & 0 \lt x \lt L \\ 0 & \text{otherwise} \end{cases}

Since the associated eigenvalue E depends on k, then E can only assume quantized values (hence the quantum in quantum mechanics):

E = \frac{\hbar^2 k^2}{2m} = \frac{\hbar^2 \pi^2}{2mL}n^2

Please note that n = 0 would yield a non normalizable eigenstate so it is not acceptable.

We can also follow a different computation approach, exploting the equality in the final note of the upper level paragraph.

From

\begin{cases} \psi(x) = A\cos(kx) + B\sin(kx) \\ \psi(0) = 0 \\ \psi(L) = 0 \end{cases}

we get that

\begin{cases} A = 0 \\ B\sin(kL) = 0 \end{cases}

thus k = \frac{n\pi}{L} and \psi(x) = B\sin(\frac{n\pi}{L}x)

If the box is symmetric (i.e. it goes from -\frac{L}{2} to +\frac{L}{2} instead of going from 0 to L) then the ground state (n=1) and all the other states with an odd n value are symmetric (in terms ow wave-function) while the ones with an even n value are antisymmetric. We will now derive thi conclusion. Since

\begin{cases} \psi(x) = A\cos(kx) + B\sin(kx) \\ \psi\left(+\frac{L}{2}\right) = 0 \\ \psi\left(-\frac{L}{2}\right) = 0 \\ \end{cases}

then

\begin{cases} A\cos\left(k\frac{L}{2}\right) + B\sin\left(k\frac{L}{2}\right) = 0 \\ A\cos\left(k\frac{L}{2}\right) - B\sin\left(k\frac{L}{2}\right) = 0 \\ \end{cases}

from which

\psi(x) = \begin{cases} 2A\cos\left(\frac{n\pi}{L} x\right) & \text{$n$ odd} \\ 2B\sin\left(\frac{n\pi}{L} x\right) & \text{$n$ even} \end{cases}

Multidimensional version

The multidimensional extension to the particle in a box is trivial: all the multidimensional equations and constraints get split into multiple monodimensional ones. Take, as an example, the three-dimensional case:

-\frac{h^2}{2m}\left( \frac{\partial^2}{\partial x^2} + \frac{\partial^2}{\partial y^2} + \frac{\partial^2}{\partial z^2} \right) \psi(x, y, z) = E \psi(x, y, z)

Since the particle is free inside the box, there are no entanglement between coordinates, so we can express

\psi(x, y, z) = X(x) Y(y) Z(z)

therefore

-\frac{\hbar^2}{2m} \left[ \left( \frac{\partial^2 X(x)}{\partial x^2} \right) Y(y) Z(z) + X(x) \left( \frac{\partial^2 Y(y)}{\partial y^2} \right) Z(z) + X(x) Y(y) \left( \frac{\partial^2 Z(z)}{\partial z^2} \right) \right] = E X(x) Y(x) Z(z) \\ E = -\frac{\hbar^2}{2m}\left[ \underbrace{\left( \frac{\partial^2 X(x)}{\partial x^2} \right) \frac{1}{X(x)}}_{g(x)} + \underbrace{\left( \frac{\partial^2 Y(y)}{\partial y^2} \right) \frac{1}{Y(y)}}_{h(y)} + \underbrace{\left( \frac{\partial^2 Z(z)}{\partial z^2} \right) \frac{1}{Z(z)}}_{l(z)} \right]

Since kinetic energy is constant w.r.t. position, all g, h, l must be constants, so we can split the equation in three:

\begin{cases} E_x = -\frac{\hbar^2}{2m}g \\ E_y = -\frac{\hbar^2}{2m}h \\ E_z = -\frac{\hbar^2}{2m}l \end{cases}

Since we already know the solution in the monodimensional case, we can write that

\begin{align*} X(x) = \sin(k_x x) &\qquad E_x = \left( \frac{\pi^2 \hbar^2}{2mL_x} \right)n_x^2 \\ Y(y) = \sin(k_y y) &\qquad E_y = \left( \frac{\pi^2 \hbar^2}{2mL_y} \right)n_y^2 \\ Z(z) = \sin(k_z z) &\qquad E_z = \left( \frac{\pi^2 \hbar^2}{2mL_z} \right)n_z^2 \\ \end{align*}

therefore

E_{tot} = E_x + E_y + E_z = \frac{\pi^2 \hbar}{2m} \left( \frac{n_x^2}{L_x} + \frac{n_y^2}{L_y} + \frac{n_z^2}{L_z} \right)

where n_x, n_y, n_z \in \mathbb{N}^+. If one of the n values were 0 it would mean that a particle has no kinetic energy in one direction therefore we could be able to measure its position with infinite precision on that direction, disprooving the Heisenberg uncertainty principle. Fortunately (?) this is impossible because that would yield a non normalizable eigenstate, which is forbidden.

Potential step

Assume we have a potential step shaped like

V(x) = \begin{cases} V_0 \gt 0 & x \lt 0 \\ 0 & x \gt 0 \end{cases}

Since particles always have positive kinetic energy, total energy eigenvalues E are always strictly greater than the minimum potential (in this case, E \gt 0).

We will now discuss the two possible case in which we an find the particle under analysis: we could either have E \gt V_0 or E \lt V_0.

We will now analyze the case where E \gt V_0. In this case, since the total energy is greater than the step, the particle does not always get reflected back. Those who get reflected keeps the same kinetic energy, the other ones see it decreased.

Since the particle will never enter the forbidden zone (a place where the potential is higher than the total energy, causing the kinetic energy to be negative), the wave function must be a piecewise sinusoidal function, with different amplitudes and phase factors on the left and on the right of the step.

In the specific piecewise context we are analyzing, the general solution can be rewritten as

\psi(x) = \begin{cases} A e^{+ ik_lx} + B e^{- ik_lx} & k_l = \sqrt{(E - V_0) \frac{2m}{\hbar^2}} & x \lt 0 \\ C e^{+ ik_rx} + D e^{- ik_rx} & k_r = \sqrt{E \frac{2m}{\hbar^2}} & x \gt 0 \end{cases}

where A is the intensity of the beam of particles going right on the left of the step, B is the intensity of the beam of particles going left on the left of the step, C is the intensity of the beam going right on the right of the step and D is the intensity of the particles going left on th right of the step. Since there are no particles coming from the left of the step, we set A = 0.

D must be given as it is the “input” beam intensity

To find the solution, we must impose that \psi \in \mathcal C^1(\mathbb{R}):

\begin{cases} \lim\limits_{x \to 0^+} \psi(x) = \lim\limits_{x \to 0^-} \psi(x) \\ \lim\limits_{x \to 0^+} \psi'(x) = \lim\limits_{x \to 0^-} \psi'(x) \\ \end{cases}

which gives

\begin{cases} B = C + D \\ k_l^2B = -k_r^2C + k_r^2D \end{cases}

which, in turn, gives

B = \frac{2k_r^2}{k_r^2 + k_l^2}D \qquad C = \frac{k_r^2 - k_l^2}{k_r^2 + k_l^2}D

We can now identify the transmission coefficient (which gives the ratio of beam that can cross the step)

T = \frac{|B|^2}{|D|^2}

and the reflection coefficient (which gives the ratio of beam that gets reflected back)

R = \frac{|C|^2}{|D|^2}

It always holds that T + R = 1

We will now analyze the case where 0 \lt E \lt V_0. In this case the particle can still trespass the step, except that it has an exponential probability (exponential w.r.t. distance from the step) to be reflected back. When the particle has trespassed the step but has not been reflected, it is in the forbidden zone where kinetic energy become negative.

All the considerations for the previus case remains true also here: when the particle enters the forbidden zone, k becomes imaginary and cancels out the i at the exponents, replacing oscilaltions with an enpoential.

Just for the sake of completism, and to highlight the subtle differences, we report here the computation again.

In this case, all the particles, eventually, gets reflected so we say that the solution is shaped like

\psi(x) = \begin{cases} Ae^{ik_lx} + Be^{-ik_lx} & k_l = \sqrt{(E - V_0)\frac{2m}{\hbar^2}} & x \lt 0 \\ Ce^{ik_rx} + De^{-ik_rx} & k_r = \sqrt{E\frac{2m}{\hbar^2}} & x \gt 0 \end{cases}

where A are the particles going right on the left of the step, B are the particles going left on the left of the step, C are the particles going right on the right of the step and D are the particles going left on the right of the step.

We continue to have A = 0 and D given.

Since E \lt V_0 then k_l \in \mathbb{C}, \Re\{k_l\} = 0, if we only consider the exponent of the non-zeroed term in the x \lt 0 equation, it becomes an increasing exponential. This is needed because going from zero towards negative infinity, the area under said exponential is bounded and can, therefore, be normalized.

Realistic potential well

A realistic potential well is like a box, except that the outer potential is finite:

V(x) = \begin{cases} V_l & x \le 0 \\ V_r & x \ge L \\ 0 & 0 \lt x \lt L \end{cases}

The reasoning for the solution follows the one for the potential step:

\psi(x) = \begin{cases} Be^{-ik_lx} & k_l = \sqrt{(E - V_l)\frac{2m}{\hbar^2}} & x \le 0 \\ Ce^{ik_0x} + De^{-ik_0x} & k_0 = \sqrt{E\frac{2m}{\hbar^2}} & 0 \lt x \lt L \\ Ee^{ik_rx} & k_r = \sqrt{(E - V_r)\frac{2m}{\hbar^2}} & x \ge L \\ \end{cases}

We have to consider multiple cases, that we will summarize in this table:

Conditions	x \le 0	0 \lt x \lt L	x \ge L
E \gt V_l \cap E \gt V_r	Oscillatory	Oscillatory	Oscillatory
E \gt V_l \cap E \lt V_r	Oscillatory	Oscillatory	Exponential decay
E \lt V_l \cap E \gt V_r	Exponential decay	Oscillatory	Oscillatory
E \lt V_l \cap E \lt V_r	Exponential decay	Oscillatory	Exponential decay

Repeating filling in numbers, we get that for x \le 0 and x \ge L we get an exponential that decreases while getting far from the well while inside the well we get oscillatory behaviour.

Imposing \psi \in \mathcal{C}^1(\mathbb{R}) we get that

\begin{cases} \lim\limits_{x \to 0^-} Be^{-ik_lx} = \lim\limits_{x \to 0^+} Ce^{ik_0x} + De^{-ik_0x} \\ \lim\limits_{x \to L^-} Ce^{ik_0x} + De^{-ik_0x} = \lim\limits_{x \to L^+} Ee^{ik_rx} \\ \lim\limits_{x \to 0^-} -ik_lBe^{-ik_lx} = \lim\limits_{x \to 0^+} ik_0Ce^{ik_0x} - ik_0De^{-ik_0x} \\ \lim\limits_{x \to L^-} ik_0Ce^{ik_0x} - ik_0De^{-ik_0x} = \lim\limits_{x \to L^+} ik_rEe^{ik_rx} \end{cases}

Which gives

\begin{cases} B = C + D \\ -ik_lB = ik_0C - ik_0D \\ Ce^{ik_0L} + De^{-ik_0L} = Ee^{ik_rL} \\ ik_0Ce^{ik_0L} - ik_0De^{-ik_0L} = ik_rEe^{ik_rL} \end{cases}

Incomplete computations.

Symmetric box consideration still applies here.

Finite potential wall

A finite potential wall is the complement of the realistic potential well:

V(x) = \begin{cases} V_0 & 0 \le x \le L \\ 0 & x \lt 0 \cup x \gt L \end{cases}

Here there are the two usual different cases to be analyzed: E \gt V_0 and $E V_0. The former will not be repeated as it is, again, a piecewise sinusoidal function.

We rewrite here the general form of the wave function in this context, with a slight twist:

\psi(x) = \begin{cases} Ae^{ik_ox} + Be^{-ik_ox} & k_o = \sqrt{E \frac{2m}{\hbar^2}} & x \lt 0 \\ Ce^{-ik_ix} + De^{ik_ix} & k_i = \sqrt{(E - V_0)\frac{2m}{\hbar^2}} & 0 \le x \le L \\ t(E)Ae^{ik_ox} & & x \gt L \end{cases}

t(E) is called trasmissivity coefficient and it is used to calculate the probability of a particle tunneling through the wall:

T(E) = |t(E)|^2 = \left|\frac{A + B}{A}\right|^2e^{-2k_iL}

T(E) decreases exponentially with the energy difference (E - V_0) and the wall thickness (L).

There is always a non-zero chance that the particle will be able to trespass the wall: this is called quantum tunneling.

The D coefficient is the one that is used to indicate the fact that the end of the wall may also reflect particles back: while in reality this number is not null, it is so small that for the sake of clarity we will assume it to be zero.

Imposing \psi(x) \in \mathcal{C}^1(\mathbb{R}) we get that

\begin{cases} A + B = C \\ |t(E)Ae^{ik_oL}|^2 = |Ce^{-ik_iL}|^2 \end{cases}

Harmonic oscillator

The quantum harmonic oscillator is the quantum equivalent of a bouncing spring and it represent the behavior of a system close to equilibrium.

For an harmonic potential shaped like

V(x) = \frac{1}{2} kx^2 = \frac{1}{2}m \omega^2 x^2

the hamiltonian can be rewritten as

\hat H = \frac{1}{2m}\hat P^2 + \frac{1}{2}\underbrace{m\omega^2}_{k}\hat X^2

We already said that energy is quantized, so there will be infinite eigenstates for this hamiltonian, indexed by n \in \mathbb{N} (this time including 0).

In general, the n-th eigenfunction can be expressed as

\psi_n(x) = C_n e^{\frac{-\alpha^2 x^2}{2}}H_n(\alpha x)

where H_n denotes the n-th physicists Hermite polynomial.

Ladder operators

Instead of using Hermite polynomials, it is easier to use ladder operators to go up and down energy levels, like with a ladder.

We define two dimensionless operators: the creation/increasing operator

\hat a^\dagger \overset{\Delta}{=} \frac{1}{\sqrt{2m\hbar\omega}} (-i \hat P_x + m \omega x)

and the destruction/annihilation/lowering operator

\hat a \overset{\Delta}{=} \frac{1}{\sqrt{2m\hbar\omega}} (+i \hat P_x + m \omega x)

Since those operatos are not hermitian, they do not correspond to any physical observable.

The hamiltonian can be rewritten making use of the ladder operators:

\hat H = \hbar \omega\left( \hat a \hat a^\dagger - \frac{1}{2} \right) = \hbar \omega \left( \hat a^\dagger \hat a + \frac{1}{2} \right) = \frac{1}{2} (\hat a^\dagger \hat a - \hat a \hat a^\dagger)

Let |n\rangle have \psi_n as a wavefunction, then the ladders operators operate on |n\rangle in the following ways:

\hat a^\dagger |n\rangle = \sqrt{n + 1}|n + 1\rangle \qquad \hat a |n\rangle = \sqrt{n}|n - 1\rangle

Energy is quantized: energy of two consecutive levels differ by \hbar \omega, therefore, since E_0 = \frac{1}{2}\hbar\omega then

E_n = E_0 + n\hbar\omega = \hbar \omega\left( n + \frac{1}{2} \right)

From the properties above, it follows that \hat a^\dagger \hat a is an operator that gives the number of energy quanta in the system

\hat a^\dagger \hat a | n \rangle = n |n\rangle

Dynamics

A dynamic system is a system that mutates over time. We already saw that, unless irreversible operations are applied on the system, knowing it’s precise state at a given moment is enough information to deterministically predict its evolution both forever in the past and in the future, we will now analyze how to do that.

We denote a time-dependent state with

|u(t)\rangle = \sum_j \alpha_j(t) |O_j\rangle \\ |u(t)\rangle = \int \psi(\xi, t)|O(\xi)\rangle d\xi

Assume that \hat H |\psi(t)\rangle = E |\psi(t)\rangle then, if \psi(t) is a solution, \psi(t + \tau) must be another valid solution.

We introduce the time translation operator \hat t_\tau such that \hat t_\tau \psi(t) = \psi(t + \tau).

Let |\psi_j(0)\rangle be an eigenstate for energy, then, its time evolution is given by

|\psi_j(t)\rangle = \hat t_t |\psi(0)\rangle = e^{\frac{-iE_jt}{\hbar}}|\psi_j(0)\rangle

therefore, if

|u(0)\rangle = \sum_j \alpha_j |psi_j(0)\rangle

its time evolution is given by

|u(t)\rangle = \sum_j \alpha_j |\psi_j(t)\rangle = \sum_j \alpha_j \hat t_t |\psi_j(0)\rangle = \sum \alpha_j e^{\frac{-iE_jt}{\hbar}} |\psi_j(0)\rangle

We define

\omega = \frac{E}{\hbar}

If a generic ket |u\rangle is a solution of the Schrödinger equation (that, from now on, will be called time-independent Schrödinger equation), then |u\rangle is called stationary state, i.e. a state whose time evolution is given simply by a multiplication by a phase factor (in practice, energy eigenstates).

A more general equation is needed: enter the time-dependent Schrödinger equation. Any ket |u(t)\rangle must be a solution of this equation for every t:

\hat H |u(t)\rangle = i \hbar \frac{d}{dt} |u(t)\rangle

The time-dependent Schrödinger equation is always valid, no matter the choice of |u(t)\rangle, as long as it is in energy representation.

We can express any time dependent ket as an entanglement of a time-independent ket and a time dependence:

|u(t)\rangle = |v\rangle e^{-i\omega t}

The hamiltonian operator \hat H only operates on the time-independent part:

\hat H |u(t)\rangle = e^{-i \omega t}\hat H|v\rangle

If we now apply the time-dependent Schrödinger equation

\begin{align*} \hat H |u(t)\rangle &= i \hbar \frac{\partial}{\partial t} |u(t)\rangle \\ e^{-i \omega t} \hat H |v\rangle &= i \hbar (-i \omega) e^{-i \omega t} |v\rangle \\ \hat H |v\rangle &= \hbar \omega |v\rangle \\ \hat H |v\rangle &= E |v\rangle \end{align*}

hence, the solution of the time-independent Schrödinger equation does not depend on time.

It may happen to have a time-dependent hamiltonian, such in the case of a particle in an oscillating electric field. The time-dependent Schrödinger equation can be extended to handle this case but it is beyond the scope of this document.

The most general expression of the time translation operator is

\hat t_t = e^{-\frac{i \hat H t}{\hbar}}

Energy and position measurement

Let |v\rangle and |w\rangle be normalized stationary states and |u\rangle = \alpha |v\rangle + \beta |w\rangle normalized, then

|u(t)\rangle = \alpha e^{-\frac{-iE_vt}{\hbar}} |v\rangle + \beta e^{-\frac{-iE_wt}{\hbar}} |w\rangle

Assume we want to measure the position in function of time on the x axis, then

\begin{align*} \langle x(t) \rangle &= \langle u(t) | \hat X | u(t) \rangle \\ &= \left( \alpha e^{\frac{iE_vt}{\hbar}} \langle v| + \beta e^{\frac{iE_wt}{\hbar}} \langle w| \right) \hat X \left( \alpha e^{-\frac{iE_vt}{\hbar}} |v\rangle + \beta e^{-\frac{iE_wt}{\hbar}} |w\rangle \right) \\ &= \alpha^2 \langle v | \hat X | v \rangle + \beta^2 \langle w | \hat X | w \rangle + \alpha \beta e^{\frac{i(E_v - E_w)t}{\hbar}} \langle v | \hat X | w \rangle + \beta \alpha e^{\frac{i(E_w - E_v)t}{\hbar}} \langle w | \hat X | v \rangle \\ &= \langle x(0) \rangle + \alpha \beta \left[ e^{\frac{i\Delta Et}{\hbar}} \langle v | \hat X | w \rangle + e^{\frac{-i\Delta Et}{\hbar}} \langle w | \hat X | v \rangle \right] \\ &= \langle x(0) \rangle + 2 \alpha \beta \Re \left\{ e^{\frac{i\Delta Et}{\hbar}} \langle v | \hat X | w \rangle \right\} \\ &= \langle x(0) \rangle + 2 \alpha \beta \langle v | \hat X | w \rangle \cos\left( \frac{\Delta Et}{\hbar} \right) \end{align*}

where we assumed that \langle v | \hat X | w \rangle \in \mathbb{C}

From the previous computation, we can conclude that the expectation value for the position is linked to the energy difference of the two “base” states.

Ehrenfest theorem

Ehrenfest theorem is one of the few things in common between quantum and classical mechanics. It is used to determine how generic observables mutate in time.

Even if this theorem is quite general and works even with time-dependent operators, we will only use it on time-independent operators.

This fantastic theorem can be used to derive the formula for the velocity of a particle, to derive the second law of thermodynamics and for much more.

While it may look at least curious that with this theorem we are able to derive conventional mechanics laws, notice that it is not in contrast with anything. In particular, this theorem does not tell us that we can know both position and velocity precisely at the same time, it just tells us how their expectation values (that implies, by definition, some uncertainty) are related.

Angular Momentum

From conventional physics angular momentum is defined as

\vec{L} \overset{\Delta}{=} \vec{r} \cdot \vec{P} = \vec{u_x} \cdot L_x + \vec{u_y} \cdot L_y + \vec{u_z} \cdot L_z \\ \vec{r} = \vec{u_x} x + \vec{u_y} y + \vec{u_z} z \qquad \vec{P} = \vec{u_x} P_x + \vec{u_y} P_y + \vec{u_z} P_z

hence

L_x = yP_z + zP_y \qquad L_y = zP_x + xP_z \qquad L_z = xP_y + yP_x

Since we know the operators for position and momentum, the quantum equivalent immediately follow:

\hat L_x = y \hat P_z + z \hat P_y \qquad \hat L_y = z \hat P_x + x \hat P_z \qquad L_z = x \hat P_y + y \hat P_x

While dealing with angular stuff, it is easier to use spherical coordinates:

\begin{cases} x = \rho\sin\theta\cos\phi \\ y = \rho\sin\theta\sin\phi \\ z = \rho\cos\theta \end{cases}

We can arbitrarily choose any quantization axis so we choose to use z (it follow that, in this case, \phi_z = \varphi).

Let \phi_x, \phi_y, \phi_z be the rotation around the corresponding axes, then

\hat L_x = -i \hbar \frac{\partial}{\partial \phi_x} \qquad \hat L_y = -i \hbar \frac{\partial}{\partial \phi_y} \qquad \hat L_z = -i \hbar \frac{\partial}{\partial \phi_z}

Enter the rotation operator:

\hat R_{\Delta \varphi} = e^{\frac{-L_z \Delta \varphi}{\hbar}}

Let \psi(\rho, \theta, \varphi) be the wave function in spherical coordinate representation, then

\hat R_{\Delta \varphi} \psi(\rho, \theta, \varphi) = \psi(\rho, \theta, \varphi + \Delta \varphi)

While position translations commute with each other, this does not happen with rotations:

[\hat L_x, \hat L_y] = i \hbar \hat L_z \qquad [\hat L_y, \hat L_z] = i \hbar \hat L_x \qquad [\hat L_z, \hat L_x] = i \hbar \hat L_y

therefore we cannot measure precise angular momentum w.r.t. more than one axis.

Since \hat L_z only operates on z, we can rewrite \psi:

\psi = \alpha(\rho, \theta)\varphi(\phi_z)

Since

-i \hbar \frac{\partial}{\partial \phi_z}\varphi(\phi_z) = L_z \varphi(\phi_z)

then

\varphi(\phi_z) = e^{-im\phi_z} \qquad L_z = \hbar m

m is called magnetic quantum number and is the quantum number associated with angular momentum (not the mass). We see that, just like energy, angular momentum is quantized as well.

Since \varphi(\phi_z) = \varphi(\phi_z + 2\pi) then e^{2im\pi} = 1, therefore m \in \mathbb{Z}.

We use |m\rangle to denote particles whose magnetic quantum number is m:

\hat L_z |m\rangle = \hbar m |m\rangle

There exist an equivalent for the ladder operators:

\hat L_\pm = \hat L_x \pm i \hat L_y

Intuitively, the ladder operators act on an eigenstate |m\rangle in the following ways:

\hat L_\pm |m\rangle = C_\pm |m \pm 1\rangle

We already know that the energy of a particle is the sum of a kinetic temr and a potential term: the kinetic term does not depent on the direction of the cartesian axes, so it is sphere-symmetric. If we assume that also V depends only on distance from the origin (more than acceptable of an assumption, that is, for example, verified in the case of electrons around a nucleous).

In such a case, \hat H is also sphere-symmetric and does not depend on rotations, so it commutes with \hat L_x, \hat L_y, \hat L_Z, therefore eigenstates of energy are also eigenstates for all these three operators. Having chosen z as the quantization axis, we cannot measure precisely angular momentum on x or y, therefore we need to introduce another operator, the square angular momentum operator defined as

\hat L^2 = \hat L_x^2 + \hat L_y^2 + \hat L_z^2

Since an eigenstate for \hat H is also an eigenstate for all the momentum-related operators defined so far, their eigenvalues will be quantized as well.

We denote with |\lambda(m), m\rangle a state that is an eigenstate both for \hat L^2 and \hat L_z:

\begin{cases} \hat L^2 |\lambda(m), m\rangle = \lambda(m) |\lambda(m), m\rangle \\ \hat L_z |\lambda(m), m\rangle = \hbar m |\lambda(m), m\rangle \end{cases}

The following relation holds between m and \lambda(m):

|m| \le \frac{\sqrt{\lambda(m)}}{\hbar}

This means that the projection of the total angular momentum on the z axis cannot be larger than the total angular momentum (how unintuitive, huh?).

It holds that \hat L_+ |\lambda(m_{max}), m_{max}\rangle = \hat L_- |\lambda(m_{min}), m_{min}\rangle = 0.

It is easy to verify that, for a given m, there may be multiple solutions to the eigenequation that does not depend on m: we have more eigenstates associated with the same eigenvalue, so we need another quantum number to index them. Enter the angular momentum quantum number, denoted with l.

We modify the notation again to keep track of l:

\begin{cases} \hat L^2 |l, m\rangle = \hbar^2 l(l+1) |l, m\rangle \\ \hat L_z |l, m\rangle = \hbar m |l, m\rangle & m \in \{ l, l-1, \dots, +1, 0, -1, \dots, -(l - 1), -l \} \end{cases}

We call degeneracy of some angular momentum quantum number l the number of possible values of m (it is the number of possible eigenstates with the same l) and it is computed with

2l + 1

From definition, it holds that

\hat L_+ \hat L_- |l, m\rangle = \hbar^2 [l(l + 1) - m(m - 1)]

therefore, even rotation speed is quantized. Who could have guessed, right?

Spin

The Pauli exclusion principle states that no more that on electron can occupy the same energy state. We will see a more formal introduction to this principle later.

The lowest evergy state so far is (n, l, m) = (1, 0, 0) except that, experimentally, two electrons can stay here. There must be another quantum number that can be used to differentiate between those two electrons. We shall call this new number spin.

Stern-Gerlach experiment

Due to the Zeeman effect, atoms in a magnetic field are deflected according to their m state. The Stern-Gerlach experiment consists in shooting silver atoms (coming from a silver coated incandescent filament) through a specially shaped magnetic field. Since silver atoms have all m = 0 (in reality is not the atom but the outer electron), they should be deflected all in the same way, except that this does not happen and in the phosphor coated screen used to see where the atoms ends up, we see two spots. This confirms the fact that there must be another internal degree of freedom that interact with magnetic field.

Spin algebra

In a former section, we have imposed periodicity of the wave function:

\varphi(\rho, \theta, \phi_z) = \varphi(\rho, \theta, \phi_z + 2\pi)

We now impose the same probability:

\begin{align*} |\varphi(\rho, \theta, \phi_z)|^2 &= |\varphi(\rho, \theta, \phi_z + 2 \pi)|^2 \\ e^{2 i m \phi_z} &= e^{2 i m (\phi_z + 2\pi)} \end{align*}

that is verified if

m = 0, \pm \frac{1}{2}, \pm 1, \pm \frac{3}{2}, \dots

Since we can have both positive and negative solutions, that explains the two spots in the Stern-Gerlach experiment.

By definition, electrons have half integer spins. This is not true for all particles, as we will see later.

We can look at the spin of a particle and consider it as a superposition of positive and negative spin, in the same way as \sqrt{x^2} is a superposition of +x and -x. Considering this interpretation, the Hilbert space describing an electron is

\mathcal{H}_{electron} = \mathcal{H}_{space} \otimes \mathcal{H}_{spin}

Let \chi_+ and \chi_- be associated with positive and negative spin, respectively, then

\chi_+ = \begin{bmatrix} 1 \\ 0 \end{bmatrix} \qquad \chi_- = \begin{bmatrix} 0 \\ 1 \end{bmatrix} \\ |u\rangle = \begin{bmatrix} \varphi(x, y, z) \\ \psi(x, y, z) \end{bmatrix} = \varphi(x, y, z) \chi_+ + \psi(x, y, z) \chi_-

Let \hat S_z be the operator associated with the spin observable on the quantization axis. We use s_z as the quantum number associated with spin:

s_z = \pm \frac{1}{2}

We also use s like we used l for the angular momentum (s_z is the equivalent of m).

For electrons, s (that is the equivalent of l for the angular momentum) is \frac{1}{2}. As with the angular momentum, this is linked with the degeneracy of the state.

Since the spin is an angular momentum, then

S_z = \hbar s_z = \pm \frac{\hbar}{2}

We may now derive the \hat S_z operator:

\hat S_z = \frac{\hbar}{2} \begin{bmatrix} 1 & 0 \end{bmatrix} \begin{bmatrix} 1 \\ 0 \end{bmatrix} - \frac{\hbar}{2} \begin{bmatrix} 0 & 1 \end{bmatrix} \begin{bmatrix} 0 \\ 1 \end{bmatrix} = \frac{\hbar}{2} \begin{bmatrix} 1 & 0 \\ 0 & -1 \end{bmatrix}

As per angular momentum, we define \hat S^2 as the operator to extract the total square spin of a particle:

\hat S^2 = \hbar s(s + 1)

There exist the ladder operators:

\hat S_+ |s, s_z\rangle = C_+(s, s_z) |s, s_z + 1\rangle \qquad C_+(l, m) = \hbar \sqrt{l(l + 1) - m(m + 1)} \\ \hat S_- |s, s_z\rangle = C_-(s, s_z) |s, s_z - 1\rangle \qquad C_-(l, m) = \hbar \sqrt{l(l + 1) - m(m - 1)}

It holds that

\hat S_+ |\frac{1}{2}, \frac{1}{2}\rangle = 0 \qquad \hat S_+ |\frac{1}{2}, -\frac{1}{2}\rangle = C_+\left( \frac{1}{2}, -\frac{1}{2} \right) |\frac{1}{2}, \frac{1}{2}\rangle = \hbar |\frac{1}{2}, \frac{1}{2}\rangle \\ \hat S_- |\frac{1}{2}, -\frac{1}{2}\rangle = 0 \qquad \hat S_- | \frac{1}{2}, \frac{1}{2}\rangle = C_- \left(\frac{1}{2}, \frac{1}{2} \right) |\frac{1}{2}, -\frac{1}{2}\rangle = \hbar |\frac{1}{2}, -\frac{1}{2}\rangle

Since

\begin{cases} \hat S_+ = \hat S_x + i \hat S_y \\ \hat S_- = \hat S_x - i \hat S_y \end{cases}

then we can extract also the \hat S_x and \hat S_y operators.

\begin{cases} \hat S_x = \frac{\hat S_+ + \hat S_-}{2} = \frac{\hbar}{2} \begin{bmatrix} 0 & 1 \\ 1 & 0 \end{bmatrix} \\ \hat S_y = \frac{\hat S_+ - \hat S_-}{2i} = \frac{\hbar}{2} \begin{bmatrix} 0 & -i \\ -i & 0 \end{bmatrix} \end{cases}

Since they correspond to physical observables, they should be hermitian. It is easy to verify that this is, in fact, true.

As if we needed another confirmation of the fact that spin is an angular momentum, those really suspicius commutation relations holds:

[\hat S_x, \hat S_y] = i \hbar \hat S_z \qquad [\hat S_y, \hat S_z] = i \hbar \hat S_x \qquad [\hat S_z, \hat S_x] = i \hbar \hat S_y

Looks familiar to you?

\hat S_x, \hat S_y and S_z matrices are called Pauli matrices.

We can now define the total spin square operator:

\hat S^2 = \hat S_x^2 + \hat S_y^2 + \hat S_z^2 = \frac{3 \hbar}{4} \begin{bmatrix} 0 & 1 \\ 1 & 0 \end{bmatrix}

We can get the projectio of the spin in an arbitrary \vec{n} direction:

\begin{align*} \hat S_n = \vec{n} \cdot \hat{\vec{S}} &= (\vec{n} \cdot \vec{u_x}) \hat S_x + (\vec{n} \cdot \vec{y}) \hat S_y + (\vec{n} \cdot \vec{u_z}) \hat S_z \\ &= \cos \theta_x \cdot \hat S_x + \cos \theta_y \cdot \hat S_y + \cos \theta_z \end{align*}

It can be demonstrated that the eigenvalues for \hat S_n are still \pm \frac{1}{2}.

Time evolution of spin in a magnetic field

As we already subtly mentioned while talking about the Stern-Gerlach experiment, spin couples with magnetic field. The hamiltonian associated with the coupling is

\hat H_{int} = \mu \cdot \vec{B} \cdot \hat{\vec{S}}

In a constant magnetic field, \vec{B} does not depend on position, so we can write

\hat H = \hat T + \hat V + \hat H_{int}

where \hat T and \hat V depends on position and \hat H_{int} depends solely on spin.

For now, we will only consider \hat H_{int}. For more information about the two other terms, see energy.

Since \hat H_int has the same eigenstates of \hat H, we can apply the time-dependent Schrödinger equation:

\hat H_{int} |\chi(t)\rangle = i \hbar \frac{d}{dt} |\chi(t)\rangle

Eigenvalues of \hat H_{int} are

E_{int} = \pm \frac{\hbar}{2}

They are the same of \hat H but multiplied by \mu B.

Let

|\chi(0)\rangle = \begin{bmatrix} a \\ b \end{bmatrix} = \alpha \begin{bmatrix} 1 \\ 0 \end{bmatrix} + \beta \begin{bmatrix} 0 \\ 1 \end{bmatrix}

be normalized, then it follows that

|\chi(t)\rangle = \alpha e^{-i \frac{\hbar \mu B t}{2 \hbar}} \begin{bmatrix} 1 \\ 0 \end{bmatrix} + \beta e^{+i \frac{\hbar \mu B t}{2 \hbar}} \begin{bmatrix} 0 \\ 1 \end{bmatrix} = \begin{bmatrix} \alpha e^{-i \frac{\mu B t}{2}} \\ \beta e^{+i \frac{\mu B t}{2}} \end{bmatrix}

We will now give the expectation values of the spin observable w.r.t. the three axes in function of time.

\langle S_z \rangle = \frac{\hbar}{2}(\alpha^* \alpha - \beta^* \beta) \\ \langle S_x \rangle = \hbar A \cos(\mu B t + \phi) \\ \langle S_y \rangle =

The oscillatory behavior described by \langle S_x \rangle and \langle S_y \rangle is called Larmor precession.

Note that \langle S_z \rangle is constant through time.

Angular momentum of composite system

We will now consider what happens considering both the spatial degree of freedom (angular momentum) and the internal degree of freedom (spin):

\hat{\vec{J}} = \hat{\vec{L}} + \hat{\vec{S}} \in \mathcal{H}_{space} \otimes \mathcal{H}_{spin}

In the case of multiple particles

\hat{\vec{J}} = \hat{\vec{J}}^{(1)} + \hat{\vec{J}}^{(2)} + \dots \in \mathcal{H}^{(1)} \otimes \mathcal{H}^{(2)} \otimes \cdots

In an isolated system we have conservation of momentum, therefore, since \vec{\hat{J}} is a sum of angular momenta, it is conserved.

The usual commutation relations still hold. Moreover,

[\hat{\vec{J}}, \hat{\vec{J}}^{(1)}] = [\hat{\vec{J}}, \hat{\vec{J}}^{(2)}] = \dots = 0

As usual, we can write

\begin{cases} \hat{\vec{J}} |J, M\rangle = \hbar J(J + 1) |J, M\rangle \\ \hat{\vec{J}}_z |J, M\rangle = \hbar M |J, M\rangle \end{cases}

We denote with |J, M, J_1, J_2\rangle the shared eigenstates between \hat{\vec{J}}, \hat{\vec{J}}_z, \left[\hat{\vec{J}}^{(1)}\right]^2 and \left[\hat{\vec{J}}^{(2)}\right]^2:

\begin{cases} \left[\hat{\vec{J}}^{(1)}\right]^2 |J, M, J_1, J_2\rangle = \hbar^2 J_1 (J_1 + 1) |J, M, J_1, J_2\rangle \\ \left[\hat{\vec{J}}^{(2)}\right]^2 |J, M, J_1, J_2\rangle = \hbar^2 J_2 (J_2 + 1) |J, M, J_1, J_2\rangle \end{cases}

Since

\begin{align*} \left[ \hat{\vec{J}}^{(1)} + \hat{\vec{J}}^{(2)} \right]^2 &= \left[\hat{\vec{J}}^{(1)}\right]^2 + \left[\hat{\vec{J}}^{(2)}\right]^2 + 2 \hat{\vec{J}}^{(1)} \hat{\vec{J}}^{(2)} \\ &= \left[\hat{\vec{J}}^{(1)}\right]^2 + \left[\hat{\vec{J}}^{(2)}\right]^2 + 2 \left[ \hat{\vec{J}}_x^{(1)} \hat{\vec{J}}_x^{(2)} + \hat{\vec{J}}_y^{(1)} \hat{\vec{J}}_y^{(2)} + \hat{\vec{J}}_z^{(1)} \hat{\vec{J}}_z^{(1)} \right] \end{align*}

then

[\hat{\vec{J}}^2, \hat{\vec{J}}_z^{(1)}] \ne 0 \qquad [\hat{\vec{J}}^2, \hat{\vec{J}}_z^{(2)}] \ne 0

We can express

|J, M, J_1, J_2\rangle = \sum \alpha(J, M, J_1, J_2) |J_1, M_1, J_2, M_2\rangle

where \alpha are the Clebsh-Gordan coefficents:

\alpha(J, M, J_1, J_2) = \langle J, M, J_1, J_2 | J_1, M_1, J_2, M_2 \rangle

Identical particles

In classical mechanics, particles are distinguishable: one can assign labels to particles and keep track of them without any problem. This is not true in quantum mechanics! It is impossible to determine where a particle is, let alone distinguish one from other identical.

We say that two particles are identical (undistinguishable) when they are described by the same quantum numbers.

Particles can be categorized in two cathegories: fermions (half integer spins) and nosons (full integer spin).

Within the fermions, we can find leptons (electrons (e, s = \frac{1}{2}), muons (\mu, s = \frac{1}{2}), taus (\tau, s = \frac{1}{2}), electron neutrinos (\nu_e, s = \frac{1}{2}), muon neutrinos (\nu_\mu, s = \frac{1}{2}), tau neutronos (\nu_\tau, s = \frac{1}{2})) and quarks (up (u, s = \frac{1}{2}), down (d, s = \frac{1}{2}), charm (c, s = \frac{1}{2}), strange (s, s = \frac{1}{2}), top (t, s = \frac{1}{2}), bottom (b, s = \frac{1}{2})).

Within the bosons, we can find Higgs bosons (H, s = 0), gluons (g, s = 1), photons (\gamma, s = 1), Zs (Z^0, s = 1), Ws (W^\pm, s = 1), gravitons (G, only theorized, s = 2).

Let |u\rangle \in \mathcal{H}^{(1)} be the quantum state deescribing a single particle. If we are considering both the position and the spin, then \mathcal{H}^{(1)} = \mathcal{H}_{space}^{(1)} \otimes \mathcal{H}_{spin}^{(1)}. In such a case, |u\rangle is composed by a vector of 2s + 1 wave functions, one for each possible spin value:

|u(\vec{r_1})\rangle = \begin{bmatrix} \varphi(\vec{r_1}) \\ \psi(\vec{r_1}) \\ \vdots \end{bmatrix}^{(1)}

For a two particle system, u can be rewritten as

|u(\vec{r_1}, \vec{r_2})\rangle = \begin{bmatrix} \varphi(\vec{r_1}) \\ \psi(\vec{r_1}) \\ \vdots \end{bmatrix}^{(1)} \begin{bmatrix} \chi(\vec{r_2}) \\ \xi(\vec{r_2}) \\ \vdots \end{bmatrix}^{(2)}

Let P_{ji} be the operator that swaps the positions of the j-th and i-th particle. This operator commutes with \hat H.

If the two particles live inaa magnetic field B and B does depend on position, P_{ji} also needs to swap the spin of the particles:

\hat P_{12} \psi(\vec{r_1}, s_1, \vec{r_2}, s_2) \ne \psi(\vec{r_2}, s_1, \vec{r_1}, s_2) \\ \hat P_{12} \psi(\vec{r_1}, s_1, \vec{r_2}, s_2) = \psi(\vec{r_2}, s_2, \vec{r_1}, s_1) \\

This is due to the fact that, in this case, \hat H has also terms depending on spin and magnetic field at the position of the particles.

Assume we have two identical particles living into a position-dependent magnetic field, then the contribution to the hamiltonian due to the coupling between the spin and the magnetic field is

\hat H_B = \vec{B}(\vec{r_1}) \cdot \hat{\vec{S_1}} + \vec{B}(\vec{r_2}) \cdot \hat{\vec{S_2}}

therefore

\hat H_B |u(\vec{r_1}, \vec{r_2})\rangle = \left( \vec{B}(\vec{r_1}) \cdot \hat S_1 \begin{bmatrix} \varphi(\vec{r_1}) \\ \psi(\vec{r_1}) \\ \vdots \end{bmatrix}^{(1)} \right) \begin{bmatrix} \chi(\vec{r_2}) \\ \xi(\vec{r_2}) \\ \vdots \end{bmatrix}^{(2)} + \left( \vec{B}(\vec{r_2}) \cdot \hat S_2 \begin{bmatrix} \chi(\vec{r_2}) \\ \xi(\vec{r_2}) \\ \vdots \end{bmatrix}^{(2)} \right) \begin{bmatrix} \varphi(\vec{r_1}) \\ \psi(\vec{r_1}) \\ \vdots \end{bmatrix}^{(1)}

thus

\hat H_B \hat P_{12} |u(\vec{r_1}, \vec{r_2})\rangle = \left( \vec{B}(\vec{r_1}) \cdot \hat S_1 \begin{bmatrix} \chi(\vec{r_1}) \\ \xi(\vec{r_1}) \\ \vdots \end{bmatrix}^{(1)} \right) \begin{bmatrix} \varphi(\vec{r_2}) \\ \psi(\vec{r_2}) \\ \vdots \end{bmatrix}^{(2)} + \left( \vec{B}(\vec{r_2}) \cdot \hat S_2 \begin{bmatrix} \varphi(\vec{r_2}) \\ \psi(\vec{r_2}) \\ \vdots \end{bmatrix}^{(2)} \right) \begin{bmatrix} \chi(\vec{r_1}) \\ \xi(\vec{r_1}) \\ \vdots \end{bmatrix}^{(1)}

What we’ve just seen here is the proof that, for a disentangled state, the hamiltonian commutes with the permutation. To extend this for a generic state, it is enough to express u\rangle as an entrangled state and to repeat the same steps.

Now consider the square permutation operator \hat P_{12}^2. Intuitively, \hat P_{12}^2 = \mathbb{I}. This means that

\hat P_{12} |\psi(\dots)\rangle = \pm |\psi(\dots)\rangle

Pauli exclusion principle

Assume a generic two-identical-particle system:

|u(\vec{r_1}, \vec{r_2})\rangle = \sum_{ji} \alpha_{ji} \begin{bmatrix} \varphi_j(\vec{r_1}) \\ \psi_j(\vec{r_1}) \end{bmatrix}^{(1)} \begin{bmatrix} \varphi_i(\vec{r_2}) \\ \psi_i(\vec{r_2}) \end{bmatrix}^{(2)}

therefore

\begin{align*} \hat P_{12} |u(\vec{r_1}, \vec{r_2})\rangle &= \sum_{ji} \alpha_{ji} \begin{bmatrix} \varphi_i(\vec{r_1}) \\ \psi_i(\vec{r_1}) \end{bmatrix}^{(1)} \begin{bmatrix} \varphi_j(\vec{r_2}) \\ \psi_j(\vec{r_2}) \end{bmatrix}^{(2)} \\ &= \sum_{ij} \alpha_{ij} \begin{bmatrix} \varphi_j(\vec{r_1}) \\ \psi_j(\vec{r_1}) \end{bmatrix}^{(1)} \begin{bmatrix} \varphi_i(\vec{r_2}) \\ \psi_i(\vec{r_2}) \end{bmatrix}^{(2)} \\ &= \pm |u(\vec{r_1}, \vec{r_2})\rangle \end{align*}

For bosons \alpha_{ji} = \alpha_{ij} and there isn’t any problem. For fermions \alpha_{ij} = -\alpha_{ji} implies that \alpha_{ji} = 0, therefore we cannot find two fermions in the same exact state.

Consequences

We will now examine three case-studies to determine how different types of identical particles interact with each other. We will see that the Pauli exclusion principle will be the confirmed every time, even in the most unintuitive scenarios.

Bosons

We can describe a generic two-identical-bosons system with

\begin{align*} \chi(\vec{r_1}, \vec{r_2}) &= \frac{1}{V \sqrt{2}} \left[ e^{-i \vec{k_1} \vec{r_1}} e^{-i \vec{k_2} \vec{r_2}} + e^{-i \vec{k_1} \vec{r_2}} e^{-i \vec{k_2} \vec{r_1}}\right] \\ &= \frac{1}{V \sqrt{2}} e^{-i (k_1 + k_2) \vec{r}_{cm}} \cos \left[ (k_1 - k_2) \frac{\Delta r}{2} \right] \end{align*}

where

\Delta \vec{r} = \vec{r_1} - \vec{r_2} \qquad \vec{r_1} = \vec{r}_{cm} + \frac{\Delta \vec{r}}{2} \qquad \vec{r_2} = \vec{r}_{cm} - \frac{\Delta \vec{r}}{2}

To find the probability density function, we square the wave function:

f(\Delta \vec{r}) = \frac{2}{V^2} \cos \left[ (k_1 - k_2) \frac{\Delta r}{2} \right]

We can see that the probability does only depend on the distance between the two particles (even if the particles are non interacting). We have a locam maximum in \Delta \vec{r} = 0, therefore there is an high probability to find the two particles in the same state in the same position, this is called Exchange interaction.

This is in agreement with the spin statistics theorem that, in this case, introduces correlation between non-interacting particles.

Same-spin fermions

Assume we have two neutron (fermions) with the same spin:

|\psi(\vec{r_1})\rangle = \begin{bmatrix} \psi(\vec{r_1}) \\ 0 \end{bmatrix}^{(1)} \qquad |\varphi(\vec{r_2})\rangle = \begin{bmatrix} \varphi(\vec{r_2}) \\ 0 \end{bmatrix}^{(2)}

We now express the state of the system:

|\chi(\vec{r_1}, \vec{r_2})\rangle = \frac{1}{\sqrt{2}} \left(|\psi(\vec{r_1})\rangle^{(1)} |\varphi(\vec{r_2})\rangle^{(2)} - |\psi(\vec{r_2})\rangle^{(2)} |\varphi(\vec{r_1})\rangle^{(1)} \right)

therefore

\begin{align*} f(\vec{r_1}, \vec{r_2}) = \langle \chi | \chi \rangle &= \frac{1}{2} \left[ \langle\varphi(\vec{r_2})|^{(2)} \langle\psi(\vec{r_1})|^{(1)} - \langle\psi(\vec{r_2})|^{(2)} \langle\varphi(\vec{r_1})|^{(1)} \right] \left[ |\psi(\vec{r_1})\rangle^{(1)} |\varphi(\vec{r_2})\rangle^{(2)} - |\psi(\vec{r_2})\rangle^{(2)} |\varphi(\vec{r_1})\rangle^{(1)} \right] \\ &= \frac{1}{2V^2} \left[ 1 + 1 - \langle \psi(\vec{r_2}) | \varphi(\vec{r_2}) \rangle^{(2)} \langle \varphi(\vec{r_1}) | \psi(\vec{r_1}) \rangle^{(1)} - \langle \psi(\vec{r_1}) | \varphi(\vec{r_1}) \rangle^{(1)} \langle \varphi(\vec{r_2}) | \psi(\vec{r_2}) \rangle^{(2)} \right] \\ &= \frac{1}{2V^2} \left[ 2 - e^{-i (k_1 r_1 - k_1 r_2)} e^{-i (k_2 r_2 - k_2 r_1)} - e^{-i (k_1 r_2 - k_1 r_1)} e^{-i (k_2 r_1 - k_2 r_2)} \right] \\ &= \frac{1}{2V^2} \left[ 2 - e^{-i (k_1 - k_2)(r_1 - r_2)} - e^{+i (k_1 - k_2)(r_1 - r_2)} \right] \\ &= \left[ 1 - \cos \left[ (r_1 - r_2) (k_1 - k_2) \right] \right] \end{align*}

Just like with bosons, we have a dependece by relative distance. If \Delta \vec{r} = 0 then P = 0, hence the impossibility of having two same-spin fermions in the same state in the same place.

Opposite-spin fermions

Assume we have two neutrons (fermions) with opposite spin:

|\psi(\vec{r_1})\rangle = \begin{bmatrix} \psi(\vec{r_1}) \\ 0 \end{bmatrix}^{(1)} \qquad |\varphi(\vec{r_2})\rangle = \begin{bmatrix} 0 \\ \varphi(\vec{r_2}) \end{bmatrix}^{(2)}

We now express the state of the system:

|\chi(\vec{r_1}, \vec{r_2})\rangle = \frac{1}{\sqrt 2} \left[ |\psi(\vec{r_1})\rangle^{(1)} |\varphi(\vec{r_2})\rangle^{(2)} - |\psi(\vec{r_2})\rangle^{(2)} |\varphi(\vec{r_1})\rangle^{(1)} \right]

therefore

\begin{align*} f(\vec{r_1}, \vec{r_2}) = \langle \chi | \chi \rangle &= \frac{1}{2} \left[ \langle\psi(\vec{r_1})|^{(1)} \langle\varphi(\vec{r_2})|^{(2)} - \langle\varphi(\vec{r_1})|^{(1)} \langle\psi(\vec{r_2})|^{(2)} \right] \left[ |\psi(\vec{r_1})\rangle^{(1)} |\varphi(\vec{r_2})\rangle^{(2)} - |\psi(\vec{r_2})\rangle^{(2)} |\varphi(\vec{r_1})\rangle^{(1)} \right] \\ &= \frac{1}{2V^2} \left[ 1 + 1 - \langle \psi(\vec{r_1}) | \varphi(\vec{r_1}) \rangle^{(1)} \langle \varphi(\vec{r_2}) | \psi(\vec{r_2}) \rangle^{(2)} - \langle \varphi(\vec{r_1}) | \psi(\vec{r_1}) \rangle^{(1)} \langle \psi(\vec{r_2}) | \varphi(\vec{r_2}) \rangle^{(2)} \right] \\ &= \frac{1}{2V^2} [2 - 0 - 0] \\ &= \frac{1}{V^2} \end{align*}

It follows that particles with opposite spins do not have any restriction of sort.

Different types of entanglement

The Einstein-Podolski-Rosen paradox

Assume we have a double slit experiment. When we throw a particle, the screen deviates the particle, therefore, since momentum conservation applies, a certain amount of momentum must me transferred to the screen. If that were the case, that momentum could be measured (except that, the screen should be so light that it could be consodered a quantum object).

Considering the screen as a quantum object all the computations make sense and agree with experimental results (experiments that, by the way, were performed not long ago).

We will now discuss a simplified version of the Einstein-Podosski-Rosen paradox (from now on, EPR).

Consider a spinless pion \pi^0. There is a non-null probability that those pion decays into a positron and a negatron (synonym for electron). Because of momentum conservation, the spin of the positron must be the opposite of the spin of the electron. Now take the positron and move it far enough so that there is time to perform a spin measurement on the electron before information can travel from the positron to the electron.

Measuring the spin of one particle would let us immediately know what will be the measurement on the other particle.

According to Bohr, measurement results are stochastic (determined at measure-time) but Einstein could not wrap his head around this spooky action at distance: he already proved that information cannot travel faster than light (otherwise the past could be influenced after it already happened) therefore, according to him, quantum physics as-is was not complete, meaning that there are some still-undiscovered hidden dynamics. This is the so-called hidden variables theory ant is is still plausible because how a pion decays is still not known. May the spin be determined at decay-time?

“Who cares, algebra works!” — Bohr to Einstein, probably.

Practically speaking, Einstein stated the local-realism hypotheses:

• realism: the value of an observable is always predetermined (ant it appears as stochastic because of some hidden dynamics we still do not know about yet);
• locality: performing a measurement in a position does not affect the measurements in a different position at superluminal speeds.

Quantum mechanics is not a local theory

How can we verify if quantum mechanics follow Einstein’s hypotheses? The following work was performed by Bell.

Consider

\psi^\pm = \frac{1}{\sqrt 2} \left( |\uparrow_z\rangle^{(1)} |\downarrow_z\rangle^{(2)} \pm |\downarrow_z\rangle^{(1)} |\uparrow_z\rangle^{(2)} \right)

be a superposition of the Bell states.

Note that we are not requiring that the particles are identical: in this way, the spin statistics theorem does not apply and we can choose any symmetry we like.

We also are considering only binary observables such as spin.

Bell introduced the correlation function

C(a, b) = \frac{S_a^{(1)} S_b^{(2)}}{\hbar^2 S^2}

Bell proved that the evaluation of C in the context of quantum mechanics would lead to very different results compared with what could be deduceb by the computation of C using the classical framework.

Quantum framework

We will now see what happens computing the value of the correlation function using the quantum framework.

Consider \psi^\pm ad defined before and consider a = z, then,

\begin{align*} \langle S_a^{(1)} S_b^{(2)} \rangle &= \langle \psi^\pm | \hat S_a^{(1)} \hat S_b^{(2)} | \psi^\pm \rangle = \langle \psi^\pm | \hat S_z^{(1)} \hat S_b^{(2)} | \psi^\pm \rangle \\ &= \frac{1}{2} \left\{ \langle\uparrow_z|^{(1)} \langle \downarrow_z|^{(2)} \hat S_z^{(1)} \hat S_b^{(2)} |\uparrow_z\rangle^{(1)} |\downarrow_z\rangle^{(2)} \pm \underbrace{\langle\uparrow_z|^{(1)} \langle\downarrow_z|^{(2)} \hat S_z^{(1)} \hat S_b^{(2)} |\downarrow_z\rangle^{(1)} |\uparrow_z\rangle^{(2)}}_{0} \pm \underbrace{\langle\downarrow_z|^{(1)} \langle\uparrow_z|^{(2)} \hat S_z^{(1)} \hat S_b^{(2)} |\uparrow_z\rangle^{(1)} |\downarrow_z\rangle^{(2)}}_{0} + \langle\downarrow_z|^{(1)} \langle\uparrow_z|^{(2)} \hat S_z^{(1)} \hat S_b^{(2)} |\downarrow_z\rangle^{(1)} |\uparrow_z\rangle^{(2)} \right\} \\ &= \frac{1}{2} \left\{ \underbrace{\langle\uparrow_z| \hat S_z |\uparrow_z\rangle^{(1)}}_{\hbar/2} \langle\downarrow_z| \hat S_b |\downarrow_z\rangle^{(2)} + \underbrace{\langle\downarrow_z| \hat S_z |\downarrow_z\rangle^{(1)}}_{-\hbar/2} \langle\uparrow_z| \hat S_b |\uparrow_z\rangle^{(2)} \right\} \\ &= \frac{\hbar}{4} \left\{ \langle\downarrow_z| \hat S_b | \downarrow_z\rangle^{(2)} - \langle\uparrow_z| \hat S_b |\uparrow_z\rangle^{(2)} \right\} \\ &= \frac{\hbar}{4} \left\{ -2 \langle \uparrow_z| \hat S_b | \uparrow_z\rangle^{(2)} \right\} \\ &= -\frac{\hbar}{2} \langle\uparrow_z| \hat S_b |\uparrow_z\rangle^{(2)} \\ &= -\frac{\hbar}{2} \left\{ \underbrace{\langle\uparrow_z| \hat S_x |\uparrow_z\rangle}_{0}\cos\theta_{xb} + \underbrace{\langle\uparrow_z| \hat S_y |\uparrow_z\rangle}_{0}\cos\theta_{yb} + \underbrace{\langle\uparrow_z| \hat S_z |\uparrow_z\rangle}_{\hbar/2}\cos\theta_{zb} \right\} \\ &= -\frac{\hbar^2}{4}\cos\theta_{zb} \end{align*}

thus, since for electrons and protons s^2 = \frac{1}{4}, then

C(a, b) = -\cos\theta_{ab}

This means that, if \theta_{ab} = 0 then C = -1 and we have perfect anticorelation (so we always measure opposite signs).

It can be demonstrated that, for

\varphi^\pm = \frac{1}{\sqrt 2} \left( |\uparrow_z\rangle^{(1)} |\uparrow_z\rangle^{(2)} \pm |\downarrow_z\rangle^{(1)} |\downarrow_z\rangle^{(2)} \right)

it holds that C = +1.

Classical framework (Bell inequality)

We will now see what happend treating the correlation function in the framework of classical mechanics (if the local-realism hypotheses were respected).

If the measurement of one quantity were not able to influence the measurement of another quantity, then, the probabilities of measuring something at one detector is not conditioned by the measurement at the other detector.

From the conservation of momentum, we know that the two spins must be opposite on the same directions. Let P(S_a^{(1)} = S_b^{(2)}) be the probability of measuring the same spin along direction a on detector (1) and along direction b on detector (2). Since we are considering only binary observables, it holds that

\langle S_a^{(1)} S_b^{(2)} \rangle = \hbar^2 s^2 P(S_a^{(1)} = S_a^{(2)}) - \hbar^2 s^2 P(S_a^{(1)} = -S_b^{(2)}) = \hbar^2 s^2 \left( 1 - 2P(S_a^{(1)} = -S_b^{(2)}) \right)

Since, again, we are considering only a binary observable, one of the three terms on the left hand side of the next inequality must be always verified:

P(S_a^{(1)} = S_b^{(1)}) + P(S_a^{(1)} = S_c^{(1)}) + P(S_b^{(1)} = S_c^{(1)}) \ge 1

For the same reason, it holds that

P(S_a^{(1)} = S_b^{(1)}) = P(S_a^{(1)} = -S_b^{(2)})

therefore we can rewrite the inequality

\begin{align*} P(S_a^{(1)} = -S_b^{(2)}) + P(S_a^{(1)} = -S_c^{(2)}) + P(S_b^{(1)} = -S_c^{(2)}) &\ge 1 \\ 1 - 2P(S_a^{(1)} = -S_b^{(2)}) + 1 - 2P(S_a^{(1)} = -S_c^{(2)}) + 1 - 2P(S_b^{(1)} = -S_c^{(2)}) &\le -2 + 3 = 1 \\ \frac{\langle S_a^{(1)} S_b^{(2)} \rangle}{\hbar^2 s^2} + \frac{\langle S_a^{(1)} S_c^{(2)} \rangle}{\hbar^2 s^2} + \frac{\langle S_b^{(1)} S_c^{(2)} \rangle}{\hbar^2 s^2} &\le 1 \\ C(a, b) + C(a, c) + C(b, c) &\le 1 \end{align*}

This last inequality is called Bell inequality and it can be rewritten in multiple equivalent forms:

\begin{align*} C(a, b) + C(a, -c) + C(b, -c) &\le 1 \\ C(a, b) - C(a, c) - C(b, c) &\le 1 \\ C(a, b) - C(a, c) &\le 1 + C(b, c) & (\dagger) \\ \end{align*}

and again

\begin{align*} C(-a, b) + C(-a, c) + C(b, c) &\le 1 \\ -C(a, b) - C(a, c) + C(b, c) &\le 1 \\ -C(a, b) + C(a, c) - C(b, c) &\le 1 \\ -C(a, b) + C(a, c) &\le 1 + C(b, c) & (\ddagger) \end{align*}

From (\dagger) and (\ddagger) it follows a stricter version of the Bell inequality:

|C(a, b) - C(a, c)| \le 1 + C(b, c)

Comparison

The Bell inequality must be respected by any theory that respect local realism.

It is easy to see that quantum mechanics does not respect the Bell inequality, therefore it is not a local-realistic theory:

\left(\theta_{ab}, \theta_{ac}, \theta_{bc}\right) = \left(\frac{\pi}{2}, \frac{\pi}{4}, \frac{\pi}{4} \right) \implies \left| 0 - \frac{\sqrt 2}{2} \right| \le 1 - \frac{\sqrt 2}{2}

that is not satisfied.

This conclusion have also been proven experimentally.

In 1972, Clauser and Freedman performed an experiment where the binary observable was photon polarization and not spin. Basically, they managed to eccitate a calcium atom to make an electron perform a double jump down from a state with J = 0 to another state with J = 0, emitting two photons.

Since the total momentum must be conserved, those two photons must have opposite polarization, the two photons must be entangled in such a characteristic. The two scientists saw that the measurements of tho polarization violates the Bell inequality therefore, at least one of the two local-realism hypotheses would need to be dropped.

Hidden variables theory

As noted before, einstein suggested that there may be some hidden dynamics we have not discovered yet that would let us determine a priori the result of measurements a priori. We will now give the proof that this is not the case.

Assume that the measurement result depends on some hidden variables \xi, then S_a^{(1)} = S_a^{(1)}(\xi) = \pm |s|.

Let f be the probability density function of \xi, then

\langle S_a^{(1)} S_b^{(2)} \rangle = \int S_a^{(1)}(\xi) S_b^{(2)}(\xi) f(\xi) d\xi = -\int S_a^{(1)}(\xi) S_b^{(1)}(\xi) f(\xi) d\xi = -\int S_a(\xi) S_b(\xi) f(\xi) d\xi

then, it follows that

\begin{align*} \langle S_a^{(1)} S_b^{(2)} \rangle - \langle S_a^{(1)} S_c^{(2)} \rangle &= -\int S_a(\xi) S_b(\xi) f(\xi) d\xi + \int S_a(\xi) S_c(\xi) f(\xi) d\xi \\ &= -\int f(\xi) \left[ S_a(\xi) S_b(\xi) - S_a(\xi) S_c(\xi) \right] d\xi \\ &= -\int f(\xi) \left[ S_a(\xi) S_b(\xi) - \frac{4}{\hbar^2} S_a(\xi) S_b(\xi)^2 S_c(\xi) \right] d\xi \\ &= -\int f(\xi) S_a(\xi) S_b(\xi) \left[ 1 - \frac{4}{\hbar^2} S_b(\xi) S_c(\xi) \right] d\xi \\ \end{align*}

therefore

\begin{align*} \left| \langle S_a^{(1)} S_b^{(2)} \rangle - \langle S_a^{(1)} S_c^{(2)} \rangle \right| &\le \int \underbrace{|f(\xi)|}_{\ge 0} \underbrace{|S_a(\xi) S_b(\xi)|}_{0 \lt \square \lt \hbar^2 / 4 } \left[ 1 - \frac{4}{\hbar^2} S_b(\xi) S_c(\xi) \right] d\xi \\ &\le \int f(\xi) \frac{\hbar^2}{4} \left[ 1 - \frac{4}{\hbar^2} S_b(\xi) S_c(\xi) \right] d\xi \\ &= \frac{\hbar^2}{2} \int f(\xi) d\xi - \underbrace{\int f(\xi) S_b(\xi) S_c(\xi) d\xi}_{\langle S_b S_c \rangle} \end{align*}

thus

|\langle S_a^{(1)} S_b^{(2)} \rangle - \langle S_a^{(1)} S_c^{(2)} \rangle| \le \frac{\hbar^2}{4} - \langle S_b^{(1)} S_c^{(1)} \rangle = \frac{\hbar^2}{4} + \langle S_b^{(1)} S_c^{(2)} \rangle

hence

\left| \frac{\langle S_a^{(1)} S_b^{(2)} \rangle}{\hbar^2/4} - \frac{\langle S_a^{(1)} S_c^{(2)} \rangle}{\hbar^2/4} \right| \le 1 - \frac{\langle S_b^{(1)} S_c^{(2)} \rangle}{\hbar^2/4} \\ |C(a, b) - C(a, c)| \le 1 + C(b, c)

We got Bell’s inequality again even considering hidden variables, therefore they are not enough to bring back the local-realism into quantum mechanics.

Quantum communication

We already said that allowing superluminal communication would mean the possibility of altering the past before it happens.

Consider the pion decay and give, for example, the electron to Alice and the proton to Bob.

Now assume that Alice measures the spin so that the wave function collapse. This may happen either before or after Bob has performed the same measurement on his particle. Either ways, Bob will always measure 50% spin up and 50% spin down and cannot know if alice has or has not already performed the measurement so there is no way to send information by performing an irreversible operation.

Now assume that Alice performs some reversible operation on her particle. We can measure the expectation value of the spin measured by Bob after the operation has been performed:

\begin{align*} \langle S_z^{(B)} \rangle &= \langle \mathcal{U^{(A)}} \psi^\pm | \hat S_z^{(B)} | \mathcal{U^{(A)}} \psi^\pm \rangle \\ &= \langle \psi^\pm | \left[ \mathcal{U}^{(A)} \right]^H \hat S_z^{(B)} \mathcal{U}^{(A)} | \psi^\pm \rangle \\ &= \langle \psi^\pm | \hat S_z^{(B)} | \psi^\pm \rangle \\ &= \langle S_z^{(B)} \rangle \end{align*}

where we used the fact that \mathcal{U}^{(A)} and \hat S_z^{(B)} commute (since they operate on different Hilbert spaces) and the fact that \mathcal{U}^{(A)} is unitary.

As we can see, even with reversible operations, there is no way for Alice to influence the expectation value of Bob’s measurements.

Quantum communications can be used to achieve secure data exchange.

Assume that Alice entangles a pair of particles and sends one to Bob and assume that a third party (Eve) is listening on the channel (where “listening” means “measuring the particles to intercept information), capturing the particles directed to Bob, measuring them, and sending to Bob a particle with the value she has observed.

Let S(\xi) be the result of the measurement performed by Eve, then we can express the expectation values of the measurement performed by Alice and Bob as

\langle S_a^{(A)} \rangle = -S(\xi) \cos\theta_{a\xi} \qquad \langle S_b^{(B)} \rangle = -S(\xi) \cos\theta_{b\xi}

The measurement performed by Eve is like an hidden variable: when Alice and Bob then performs a correlation check, they see that they never violate The Bell inequality, meaning that there is something wrong.

Ultima modifica:

Scritto da: Andrea Oggioni
